VONETS WiFi Bridge 2.4GHz Wireless Ethernet Bridge Signal Repeater WiFi Hotspot RJ45 to WiFi Convert for DVR, Monitoring, IP Printer, Network Device VAP11G-300 with Power Supply Adapter

From the brand

VONETS WiFi Router/Bridge

Gigabit, Dual-band 2.4GHz/5GHz,10/100/1000Mbps, WiFi Router/Bridge/Repeater, can achieve WiFi to Ethernet or Ethernet to WiFi convert.

VONETS with a simple mission: Share the network with your garage, warehouse, Farm, Garden. Products: WiFi Router, WiFi Bridge, WiFi Repeater, Module, WiFi Serial Port Server, PoE Switch, etc Network Devices.

What can a Wireless Bridge do?

It is equivalent to a network cable, transmitting network signals/data via wireless communication technology way.

Convert WiFi to Ethernet or Ethernet to WiFi, and can also extend your Network devices range.

WiFi Router/Bridge/PoE Switch

Gigabit Router/Bridge

WiFi Bridge/Gigabit PoE Switch

Dual band Bridge PoE Switch

2.4G 5G WiFi Bridge/Module

【WiFi Bridge/Repeater】Industrial mini 2.4GHz WiFi Bridge Repeater Wireless Ethernet Bridge RJ45 to WiFi Adapter WiFi Hotspot Signal extend cover; can achieve Wireless to Wired or Wired to Wireless function (WiFi to Ethernet or Ethernet to WiFi convert); support WiFi 802.11b/g/n, WiFi rate:300Mbps.
【Multiple Application Methods】WiFi Bridge: can smart control the device’s WiFi mode ( IP layer or MAC layer transparent transmission); WiFi Repeater (extend the distance of WiFi transfer); WiFi Access Point hotspots. One 10/100Mbps adaptive Ethernet port (one 30cm cable with 1 male DC port and 1 male USB port).
【Connect Wired Device to WiFi】Good Partner for monitoring, electronic scales, DVR, IP camera, medical devices, IoT devices, video transmission, Industrial PLC, AGV, PS3, Network Printer, Robot and more Network devices and applications. Point-to-Point Transmission: maximum can be up to 80 meters when without obstacle and small data, then less than 50 meters when used for video transmission.
【Power&Parameters】USB or DC optional powered mode, powered by wide voltage DC5V-15V(Typical Standard 5V/2A or 12V/1A, ripple less than 100mV), With a 12V/1A Power supply adapter; the average power consumption is less than 2.5W; WiFi Tx Power:14.5dBm/16dBm optional(Enhanced Power), 2*1.5dBi internal antennas.
【Function&Note】 Support SSA signal strength detection reporting function, motion detection function and memory hotspot(Up to 100) automatic matching connection function, realize to WiFi motion applications. Please pay attention three power methods(USB, power hole, power plug) can’t be powered together, or the device may be damaged.
